Toshiba NVSPRO servers are designed for high-performance, large storage applications. With capacities up to 24TB and 64TB, Intel Core i7 processors, and dual Gigabit Ethernet ports, the NVSPRO is capable of handling demanding high-megapixel, enterprise-class deployments. Available in either 2U or 4U rackmount chassis.
FREE SOFTWARE UPGRADE FOR LIFE OF RECORDER / NO ANNUAL FEES
Click here to activate your software
| Dimensions | |
|---|---|
| Dimensions (h x w x d) | 2U: 3.3" x 17.2" x 27" / 4U: 6.9" x 16.95" x 26.25" |
| Rackmount Size | 2U / 4U |
| Weight | 48 lbs / 59 lbs |
| Frame Rates | |
| Analog Live Viewing Rate (PPS) | - |
| Analog Recording Rate (PPS) | - |
| IP Video Throughput | 200 Mbps (Non-RAID), 400 Mbps (RAID5) |
| Inputs/Outputs | |
| Alarm Outputs | - |
| Audio Inputs | 16 1 |
| LAN | Dual 100/1000 Gigabit Ethernet |
| Sensor/Alarm Inputs | - |
| USB Ports | 2U: 3 x 2.0; 2 x 3.0; 4U: 4 x 2.0; 2 x 3.0 |
| Overview | |
| Analog Video Inputs | - |
| Image Compression | H.264, MPEG4, MPJEG |
| IP Video Inputs | Up to 64 2 |
| Max Number of Channels | 64 |
| Video Outputs | HDMI, display port, DVI-D, VGA |
| Power | |
| Power Input | AC 100-240V (50Hz/60Hz) |
| Redundant Power Supply | Yes (optional) |
| Remote Clients Included | |
| Browser Client | iDVR |
| Managed Recorder Health | MySurveillix |
| Tablet Apps | iPad/Android |
| VMS Software | Surveillix SCS |
| Storage | |
| External Storage | iSCSI (optional) |
| Max Number HDD | 2U: 6 removable; 4U: 16 removable |
| Optical Drive | DVD/RW |
| RAID Configuration (optional) | RAID5 |
| Storage capacity | Up to 96TB |
| System | |
| CPU | Intel Core i7 |
| Operating System | Windows 7 Embedded |
| Recording Software | Surveillix (included) |
| Warranty | |
| Limited Warranty | 3 years, 1 year advanced replacement |
| Designs and specifications are subject to change without notice. | |
