The Toshiba IKS-WR7412 is a 1080p outdoor dome IP camera with solid features for a wide variety of challenging outdoor applications. Combining 1080p resolution, IP66 rated housing, IR illuminators and true D/N imaging make this IP camera a smart choice for any system. Also, features like 3-axis gimbal, ONVIF compliance and 802.3af PoE ensure quick, cost-effective installations.
| Camera | |
|---|---|
| Angle of view | 90.3° horizontal |
| Effective Pixels | 1920 x 1080 |
| Image Sensor | 1/2.8" CMOS 2MP |
| IR Illuminators | 24 IR LED illuminators (850nm) Up to 50 feet |
| Lens | Fixed f=2.8mm, F2.0 |
| Lens Type | Fixed focus |
| Minimum Illumination | 0.1 lux, 0.0 lux with IR on |
| Zoom | Digital |
| Features | |
| BLC | Yes |
| Day/Night | Yes, IR cut filter |
| Gain (AGC) | Auto |
| Motion detection | Yes |
| Privacy mask | Yes |
| Tamper protection | Yes |
| White Balance | Auto, manual, ATW (2450 - 10500K) |
| Wide Dynamic Range | Digital WDR |
| General | |
| Dimensions | 3.125” (H) x 4.625 inch (Dia.) (79.4mm x 117mm) |
| Environmental | IP66 |
| Operation Humidity | ~ 90% |
| Operation Temperature | 14° F to 122° F (-10° C to 50° C) |
| Power Consumption | 5.8W |
| Power Requirements | 802.3af PoE |
| Weight | 0.73 lbs (330g) |
| Interface | |
| Digital In/Out | - |
| Ethernet Connectors | 10 Base-T/100 Base-TX, RJ45 connector |
| SD Card Slot | Micro SD/SDHC, max 32GB |
| Network | |
| Alarm Recording | FTP, email, microSD card |
| Bandwidth control | QoS |
| Basic Authorization | Yes (Windows standard) |
| Camera set-up program | Device Search |
| Maximum user access | 20 clients |
| ONVIF | Profile S |
| Plug-In | Active X |
| Protocols | IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF |
| Security | Multi level ID/Password, IP address filtering, HTTPS, 802.1x portbased authentication |
| Video | |
| Compression | H.264, MJPEG |
| Frame rate (max) | Up to 30 fps @ 1080p 1 |
| Resolutions | 1920x1080, 1280x1024, 1280x720, 720x480, 352x240 |
| Warranty | |
| Limited Warranty | 2 years parts and labor |
| Designs and specifications are subject to change without notice. | |
