Exceptionally lightweight and compact, the Toshiba IKS-WD6112 two-megapixel IP dome camera is designed for seamless integration with Toshiba and other ONVIF recording solutions. It combines the convenience of PoE with the imaging quality of 1080p HD resolution, H.264 video compression and quad stream transmission. Thanks to Wide Dynamic Range, it also delivers optimal performance in areas with large variation between light and dark.
Live Demo
| Audio | |
|---|---|
| Audio compression | G.726, G711 |
| Audio In/Out | 1 IN / 1 OUT |
| Camera | |
| Effective Pixels | 1920 x 1080 |
| Electric Shutter | 1-1/10,000 sec |
| Image Sensor | 1/2.8" CMOS 2MP |
| IR Illuminators | - |
| Lens | Fixed f=3.6mm, F=1.8 |
| Minimum Illumination | 0.1 lux @ F1.8, 30 IRE |
| Zoom | 8x digital |
| Features | |
| BLC | On/Off |
| Day/Night | Yes, electronic |
| Motion detection | Yes 1 |
| Privacy mask | Yes 2 |
| White Balance | Manual, AWB (2700K - 7800K), ATW (2450K - 10,500K) |
| Wide Dynamic Range | Digital WDR |
| General | |
| Dimensions | 1.75" (H) x 4.625" (D) (44.45mm x 117.5mm) |
| Operation Humidity | ~ 90% |
| Operation Temperature | 14° F to 122° F (-10° C to 50° C) |
| Power Consumption | 3.5W |
| Power Requirements | 802.3af PoE |
| Weight | 0.4 lbs (180g) |
| Interface | |
| Digital In/Out | - |
| Ethernet Connectors | 10 Base-T/100 Base-TX, RJ45 connector |
| SD Card Slot | MicroSD max 16GB |
| Network | |
| ONVIF | Profile S |
| Protocols | IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF |
| Video | |
| Compression | H.264, MJPEG |
| Frame rate (max) | 30 fps @ 1920x1080 3 |
| Resolutions | 1920x1080, 1280x1024, 1280x720, 720x480, 352x240 |
| Video streams | Quad streaming |
| Warranty | |
| Limited Warranty | 2 years parts and labor |
| Designs and specifications are subject to change without notice. | |
