The IK-WD04A is a 720p HD IP mini-dome camera that is ideal for a variety of indoor video surveillance environments. With wide dynamic range and multiple H.264 streaming capabilities, it delivers excellent imaging quality and operator flexibility. Unlike most cameras in its price range that have fixed lens, the IK-WD04A has a varifocal 3mm - 12mm lens, adding to its performance and value. ONVIF compliance and 802.3af Power over Ethernet simplifies installation.
Live Demo
| Audio | |
|---|---|
| Audio In/Out | - |
| Camera | |
| Effective Pixels | 1280 x 800 |
| Image Sensor | 1/4" CMOS |
| IR Illuminators | - |
| Lens | Varifocal f=3-12mm, 4x optical zoom |
| Minimum Illumination | 0.38 lux / F1.4 |
| Features | |
| Day/Night | Yes, electronic |
| Wide Dynamic Range | Digital WDR |
| General | |
| Dimensions | 3.15” (H) x 4.33” (D); (80mmx110mm) |
| Environmental | - |
| Operation Temperature | 14° F to 122° F (-10° C to 50° C) |
| Power Consumption | 3.84W max |
| Power Requirements | 12V DC ±10%, 802.3af class 3 PoE |
| Weight | 1.1 lbs (500g) |
| Interface | |
| Digital In/Out | 1 IN |
| SD Card Slot | Yes, max 32GB |
| Network | |
| ONVIF | Yes, ver 1.02 |
| Video | |
| Composite Output | Yes |
| Compression | H.264, MPEG4, MPJEG |
| Frame rate (max) | 30 fps @ 1280x800 1 |
| Resolutions | 1280x800, 640x400, 320x200, 176x144 |
| Warranty | |
| Limited Warranty | 2 years parts and labor |
| Designs and specifications are subject to change without notice. | |
