The IK-WR14A reduces upfront installation time with its incorporation of remote optical zoom, one-touch remote focus, and a new cable management system based on PoE. H.264 and SRLED allow capture of 1080p full HD resolution video at 30 fps in any lighting condition. ONVIF compliance means the camera is interoperable with third-party IP solutions, while its vandal resistant IP66 metal housing is rugged for outdoor deployments.
Live Demo
| Audio | |
|---|---|
| Audio In/Out | MIC In (plug-in 3.3V, 200k); LINE OUT (1 Vms) 1 |
| Camera | |
| Effective Pixels | 1920 x 1080 |
| Image Sensor | 1/2.7" CMOS 2MP |
| IR Illuminators | SRLED 20m range 2 |
| Lens | Varifocal f=3-9mm, 3x remote zoom, remote focus |
| Minimum Illumination | 0.04 lux / F1.2 (Night mode, LED OFF, Gain 100%, Exposure time 1/30); 0.0 lux IR on |
| Features | |
| Day/Night | Yes, IR cut filter |
| Wide Dynamic Range | Yes |
| General | |
| Dimensions | 6.8” (H) x 4.5” (D); (173mmx115mm) |
| Environmental | IK10, IP66 |
| Operation Temperature | PoE: -22° F to 122° F 12V DC and 24V AC: -13° F to 122° F |
| Power Consumption | 15.4W max |
| Power Requirements | 12V DC ±10%, 24V AC ±10% 60Hz, 802.3af class 3 PoE |
| Weight | 2.98 lbs (1350g) |
| Interface | |
| Digital In/Out | 1 IN / 1 OUT |
| SD Card Slot | Yes, max 32GB |
| Network | |
| ONVIF | Yes, ver 1.02 |
| Video | |
| Composite Output | NTSC and PAL |
| Compression | H.264, MPEG4, MPJEG |
| Frame rate (max) | Up to 30 fps @ 1080p 3 |
| Resolutions | 1920x1080, 1280x1024, 1280x720, 1024x768, 640x480, 320x240 |
| Warranty | |
| Limited Warranty | 2 years parts and labor |
| Designs and specifications are subject to change without notice. | |
