The Toshiba IK-WR05A IP camera has a wide angle, pre-focused lens and IR LEDs, making it ideal for wide area surveillance. With a 110 degree viewing angle, 1080p HD resolution and IR LEDs, the IK-WR05A can cover almost all surveillance requirements. IP66 rated housing and small form factor make it environmentally and visually appealing.
Live Demo
| Audio | |
|---|---|
| Audio In/Out | - |
| Camera | |
| Effective Pixels | 1920 x 1080 |
| Image Sensor | 1/2.7" CMOS 2MP |
| IR Illuminators | 15m range |
| Lens | Fixed f=2.8mm, 4x digital zoom, 110° viewing angle |
| Minimum Illumination | 0.05 lux (color); 0.001 lux (B/W); 0 lux with IR on |
| Features | |
| Day/Night | Yes, IR cut filter |
| Wide Dynamic Range | Yes |
| General | |
| Dimensions | 3.7” (H) x 5.24” (D); (94mmx133mm) |
| Environmental | IK10, IP66 |
| Operation Temperature | -4° F to 122° F (-20° C to 50° C) |
| Power Consumption | 3.8W max |
| Power Requirements | 802.3af PoE, 12V DC |
| Weight | 1.1 lbs (500g) |
| Interface | |
| Digital In/Out | 1 IN |
| SD Card Slot | SD/SDHC, max 32GB |
| Network | |
| ONVIF | Yes, Profile S and ver 1.02 |
| Video | |
| Composite Output | Yes |
| Compression | H.264, MPEG4, MPJEG |
| Frame rate (max) | 30 fps @ 1920x1080 1 |
| Resolutions | 1920x1080, 1280x1024, 1280x720, 1024x768, 640x480, 320x240 |
| Warranty | |
| Limited Warranty | 2 years parts and labor |
| Designs and specifications are subject to change without notice. | |
