With remote zoom and One Touch auto focus, the IK-WD14A makes for faster installation and easier setup. H.264 compression, full 1080p HD video ensures high definition, low bandwidth streaming while advanced SR LED illuminators and wide dynamic range meets various demanding lighting applications. ONVIF compliant for plug and play compatibility with NVRs.
Live Demo
| Audio | |
|---|---|
| Audio In/Out | MIC In (plug-in 3.3V, 200k); LINE OUT (1 Vms) 1 |
| Camera | |
| Effective Pixels | 1920 x 1080 |
| Image Sensor | 1/2.7" CMOS 2MP |
| IR Illuminators | SRLED 20m range 2 |
| Lens | Varifocal f=3-9mm, 3x remote zoom, remote focus |
| Minimum Illumination | 0.04 lux / F1.2 (Night mode, LED OFF, Gain 100%, Exposure time 1/30); 0.0 lux IR on |
| Features | |
| Day/Night | Yes, IR cut filter |
| Wide Dynamic Range | Yes |
| General | |
| Dimensions | 6.3” (H) x 4.3” (D); (160mmx109mm) |
| Environmental | - |
| Operation Temperature | 32°F to 122°F (0°C to 50°C) |
| Power Consumption | 15.4W max |
| Power Requirements | 12V DC ±10%, 24V AC ±10% 60Hz, 802.3af class 3 PoE |
| Weight | 1.83 lbs (830g) |
| Interface | |
| Digital In/Out | 1 IN / 1 OUT |
| SD Card Slot | Yes, max 32GB |
| Network | |
| ONVIF | Yes, ver 1.02 |
| Video | |
| Composite Output | NTSC and PAL |
| Compression | H.264, MPEG4, MPJEG |
| Frame rate (max) | 30 fps @ 1080p 3 |
| Resolutions | 1920x1080, 1280x1024, 1280x720, 1024x768, 640x480, 320x240 |
| Warranty | |
| Limited Warranty | 2 years parts and labor |
| Designs and specifications are subject to change without notice. | |
